SKU: 890008854
Megger Easyloc House Connection Set, US-plug version — connection-lead bundle for tracing services from a building to the main line. Direct-connect leads for standard mains, cable TV, and telephone sockets; the Easyloc TX transmitter plugs into the relevant socket to inject signal onto the in-house circuit. Pairs with any Easyloc RX receiver. (German-plug = 890008852; UK-plug = 890008853.)
List price. Volume pricing available.
Easyloc House Connection Set — US-plug Version.
Connection-lead bundle for the Megger Easyloc family that lets operators inject the locating signal directly into a building's in-house wiring at a wall socket — so the Easyloc TX transmitter can trace services running from inside the building back to the main line without requiring access to underground splice points.
The set comprises connecting cables for three socket types: standard 13 A / 15 A safety electricity sockets, cable TV (CATV) sockets, and telephone sockets. Plug the appropriate adapter into the wall socket, connect the other end to the Easyloc TX transmitter, and the transmitter applies its 33 kHz signal to the cable behind the socket. Walk the route with any Easyloc RX receiver to follow the cable run.
Three regional variants exist for the different mains-plug standards: 890008852 (German Schuko), 890008853 (UK BS1363), 890008854 (US NEMA 5-15) — this product. Pairs with Easyloc TX Basic/Standard (890005586) or TX Plus (890016200), and with any Easyloc RX receiver.
The Megger Easyloc House Connection Kit (US) # 890008854 is manufactured by Megger. Valley Instrument Service is an authorized Megger dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681This product is part of a family with 2 models. Select a model below to view details.
| Model | Price | |
|---|---|---|
1015109 | Request Quote | View Details → |
890008854Current | Request Quote | Viewing |
Accessories, replacement sensors, and parts for this product family.
| Model | Price | |
|---|---|---|
2010176 | Request Quote | View Details → |
890005586 | Request Quote | View Details → |
890003780 | Request Quote | View Details → |
890008650 | Request Quote | View Details → |
AccuTrace transmitter/receiver pair for tracing buried pipes and cables. Transmitter applies a low-frequency signal to the cable; receiver tracks the signal above ground to follow the route and estimate burial depth. For de-energized cables and pipes; pairs with the 656626 ring clamp for inductive coupling on cables that cannot be opened for direct connection.
Battery 9.6V NiMH 1.5AH (X8)
CFL510G Time Domain Reflectometer
Compact dual-channel time domain reflectometer for locating high- and low-impedance faults on paired metallic telecom cables. 0.1 m resolution, up to 20 km range, velocity factor 0.2–0.99, five output impedances (25–125 Ω) with auto-match. Xpert mode auto-positions the cursor on fault events; stores up to 100 traces. IP54 ingress protection, CAT IV 150 V / CAT III 300 V; ships with TraceXpert PC software.
