SKU: TTM050C-206A-CF-LI6-H1140-L100-50/50°C
-50…50 °C · For compression fittings, thermowell or direct mounting
List price. Volume pricing available.
Temperature Detection — With Current Output
The Turck Temperature Detection - With Current Output # TTM050C-206A-CF-LI6-H1140-L100-50/50°C is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101249538 |
| eCl@ss-Code (V5.1.4) | 27200206 -/- Transducer (temperature) |
| Customs tariff number | 7616995190 |
| Country of origin | DE |
| Weight | 28 g |
| Detection type | medium contact |
| Design | Without display (integrated probe) |
| Measuring range | -50…50 °C |
| Immersion depth L | 100 mm |
| Process connection | For compression fittings, thermowell or direct mounting |
| Operating voltage | 5.5…32 VDC |
| Current output | 4…20 mA |
| Measuring element | Pt1000 |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Stainless-steel/Plastic, 1.4404 (AISI 316L) |
| Ambient temperature | -40…+80 °C |
| Protection class | IP67 |
| Approvals | CE |
