SKU: WIM100-Q25L-LIU5X2-H1141
Magnetic · 100 mm [3.94 in] · Analog output · Connector, M12 × 1
List price. Volume pricing available.
Magnetically Actuated Linear Position Sensor
The Turck Magnetically Actuated Linear Position Sensor # WIM100-Q25L-LIU5X2-H1141 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101200539 |
| eCl@ss-Code (V5.1.4) | 27270705 -/- Magnetic linear position sensor |
| Customs tariff number | 7907002000 |
| Country of origin | DE |
| Weight | 300 g |
| Design | Profile |
| Measuring principle | Magnetic |
| Measuring range | 100 mm [3.94 in] |
| Operating voltage | 15…30 VDC |
| Output function | Analog output |
| Voltage output | 0…10 V |
| Current output | 4…20 mA |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Aluminum/plastic, PA6-GF30 |
| Ambient temperature | -25…+75 °C |
| Protection class | IP67 |
