SKU: LRS510-10-51-LI2UPN8-H1141
350…10000 mm · 132.3 x 38 x 50.2 mm, LRS · 10° · PNP/NPN, analog output
List price. Volume pricing available.
Radar Sensor — Level Control
The Turck Radar Sensor - Level Control # LRS510-10-51-LI2UPN8-H1141 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101514513 |
| eCl@ss-Code (V5.1.4) | 27200505 -/- Radar level measurement |
| Customs tariff number | 9026102040 |
| Country of origin | DE |
| Weight | 440 g |
| Function | Radar scanner |
| Design | With display (integrated probe) |
| Construction size | 132.3 x 38 x 50.2 mm, LRS |
| Range | 350…10000 mm |
| Frequency range | 122 - 123 GHz |
| Beam angle | 10° |
| Operating voltage | 17…33 VDC |
| Switching element function | NO/NC programmable |
| Output function | PNP/NPN, analog output |
| Voltage output | 0…10 V |
| Current output | 4…20 mA |
| Communication protocol | IO-Link |
| Electrical connection | Connector, M12 × 1 |
| Process connection | G 3/4'' |
| Housing material | Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0 PEEK |
| Ambient temperature | -25…+65 °C |
| Protection class | IP67/IP69K |
