SKU: LI500P1-Q25LM2-LIU5X3-H1151
Inductive · 500 mm [19.69 in] · Analog output · Connector, M12 × 1
List price. Volume pricing available.
Inductive Linear Position Sensor
The Turck Inductive Linear Position Sensor # LI500P1-Q25LM2-LIU5X3-H1151 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101234602 |
| eCl@ss-Code (V5.1.4) | 27270702 -/- Inductive linear position sensor |
| Customs tariff number | 9032896075 |
| Country of origin | DE |
| Weight | 802 g |
| Design | Profile |
| Measuring principle | Inductive |
| Measuring range | 500 mm [19.69 in] |
| Operating voltage | 15…30 VDC |
| Output function | Analog output |
| Voltage output | 0…10 V |
| Current output | 4…20 mA |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Aluminum/plastic, PA6-GF30, Anodized |
| Ambient temperature | -25…+70 °C |
| Protection class | IP67 |
