SKU: IM12-TI02-1TCURTDR-1I1R-C0/24VDC
Temperature measuring amplifier · Temperature input · 1 · 24 VDC · cULus
List price. Volume pricing available.
Temperature measuring amplifier — 1-channel
The Turck Temperature measuring amplifier - 1-channel # IM12-TI02-1TCURTDR-1I1R-C0/24VDC is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101419658 |
| eCl@ss-Code (V5.1.4) | 27200206 -/- Transducer (temperature) |
| Customs tariff number | 8543709860 |
| Country of origin | DE |
| Weight | 167 g |
| Signal type | Temperature input |
| Device type | Temperature measuring amplifier |
| Ex version | no |
| Approvals | cULus |
| Functional safety (SIL/PL) | SIL2 |
| Nominal voltage | 24 VDC |
| Number of channels | 1 |
| Digital output | Relay output |
| Electrical connection | Removable screw terminals, 2-pin |
| Protection class | IP20 |
| Product series | IM(X)12 |
1 · Power bridge 24 VDC · ATEX, IECEx, NEPSI
