SKU: DW1000-110-7E-H1441
Potentiometer · 1000 mm [39.37 in] · Analog output · Connector, M12 × 1
List price. Volume pricing available.
Draw-Wire
The Turck Draw-Wire # DW1000-110-7E-H1441 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101256857 |
| eCl@ss-Code (V5.1.4) | 27270790 -/- Sensor for length, path (not classified) |
| Customs tariff number | 9031804000 |
| Country of origin | DE |
| Weight | 911 g |
| Design | Draw Wire |
| Measuring principle | Potentiometer |
| Measuring range | 1000 mm [39.37 in] |
| Operating voltage | 12…30 VDC |
| Output function | Analog output |
| Current output | 4…20 mA |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Titanium anodized aluminium |
| Ambient temperature | -20…+60 °C |
| Protection class | IP65 |
