BL compact multiprotocol fieldbus station for Industrial Ethernet - 4 Analog Current or Voltage Inputs and 4 Analog Voltage Outputs

Name: Valley Instrument Service
Address: 3536 Brian Way, Bakersfield, CA, 93308, US
Telephone: (661) 327-8681

SKU: BLCEN-8M12LT-4AI4AO-VI-4AI-VI

I/O Module, Compact station, Field Logic Controller (ARGEE) · Analog input, Analog output, Analog input/output · M12

$1,370.70

List price. Volume pricing available.

Qty:

Authorized Dealer

Calibration Available

Nationwide Shipping

Expert Support

BL compact multiprotocol fieldbus station for Industrial Ethernet — 4 Analog Current or Voltage Inputs and 4 Analog Voltage Outputs

On-machine Compact fieldbus I/O block
EtherNet/IP, Modbus TCP, or PROFINET slave
Integrated Ethernet Switch
10 Mbps / 100 Mbps supported
Two 4-pole M12, D-coded, connectors for fieldbus connection
2 rotary switches for node address
IP67, IP69K
M12 I/O connectors
LEDs indicating status and diagnostics
Electronics galvanically separated from the field level via optocouplers
4 analog inputs for current or voltage
0/4…20 mA or -10/0…+10 VDC (selectable per channel)

The Turck BL compact multiprotocol fieldbus station for Industrial Ethernet - 4 Analog Current or Voltage Inputs and 4 Analog Voltage Outputs # BLCEN-8M12LT-4AI4AO-VI-4AI-VI is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.

Have questions about this product?

Our team can help with product selection, specs, pricing, and application support.

BL compact multiprotocol fieldbus station for Industrial Ethernet - 4 Analog Current or Voltage Inputs and 4 Analog Voltage Outputs

SKU: BLCEN-8M12LT-4AI4AO-VI-4AI-VI

I/O Module, Compact station, Field Logic Controller (ARGEE) · Analog input, Analog output, Analog input/output · M12

$1,370.70

List price. Volume pricing available.

Qty:

Authorized Dealer

Calibration Available

Nationwide Shipping

Expert Support

BL compact multiprotocol fieldbus station for Industrial Ethernet — 4 Analog Current or Voltage Inputs and 4 Analog Voltage Outputs

On-machine Compact fieldbus I/O block
EtherNet/IP, Modbus TCP, or PROFINET slave
Integrated Ethernet Switch
10 Mbps / 100 Mbps supported
Two 4-pole M12, D-coded, connectors for fieldbus connection
2 rotary switches for node address
IP67, IP69K
M12 I/O connectors
LEDs indicating status and diagnostics
Electronics galvanically separated from the field level via optocouplers
4 analog inputs for current or voltage
0/4…20 mA or -10/0…+10 VDC (selectable per channel)

Have questions about this product?

Our team can help with product selection, specs, pricing, and application support.

eCl@ss-Code (V5.1.4)	27250313 -/- Communication interface, passive
Customs tariff number	8536908530
Country of origin	US
Weight	1100 g
Fieldbus Protocol	Modbus TCP, EtherNet/IP, PROFINET
Signal type	Analog input, Analog output, Analog input/output
Connection technology signal	M12
Device type	I/O Module, Compact station, Field Logic Controller (ARGEE)
Fieldbus transmission rate	10/100 Mbps
Fieldbus connection technology	2 × M12
Ambient temperature	-40…+70 °C
Protection class	IP67/IP69K

eCl@ss-Code (V5.1.4)	27250313 -/- Communication interface, passive
Customs tariff number	8536908530
Country of origin	US
Weight	1100 g
Fieldbus Protocol	Modbus TCP, EtherNet/IP, PROFINET
Signal type	Analog input, Analog output, Analog input/output
Connection technology signal	M12
Device type	I/O Module, Compact station, Field Logic Controller (ARGEE)
Fieldbus transmission rate	10/100 Mbps
Fieldbus connection technology	2 × M12
Ambient temperature	-40…+70 °C
Protection class	IP67/IP69K
