BL compact fieldbus station for DeviceNet - 8 Analog Inputs for Thermocouple Elements

Name: Valley Instrument Service
Address: 3536 Brian Way, Bakersfield, CA, 93308, US
Telephone: (661) 327-8681

SKU: BLCDN-8M12L-4AI-TC-4AI-TC

I/O Module, Compact station · Analog input, Temperature · M12

$1,408.50

List price. Volume pricing available.

Qty:

Authorized Dealer

Calibration Available

Nationwide Shipping

Expert Support

BL compact fieldbus station for DeviceNet — 8 Analog Inputs for Thermocouple Elements

On-machine Compact fieldbus I/O block
DeviceNet slave
125 / 250 / 500 kbps
Two 5-pole M12 connectors for fieldbus connection
2 rotary switches for node address
IP67, IP69K
M12 I/O connectors
LEDs indicating status and diagnostics
Electronics galvanically separated from the field level via optocouplers
8 analog inputs for Thermo Couples
Types B, C, E, G, J, K, N, R, S or T (selectable per channel)
Cold-junction compensation via a Pt1000 in special connector

The Turck BL compact fieldbus station for DeviceNet - 8 Analog Inputs for Thermocouple Elements # BLCDN-8M12L-4AI-TC-4AI-TC is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.

Have questions about this product?

Our team can help with product selection, specs, pricing, and application support.

BL compact fieldbus station for DeviceNet - 8 Analog Inputs for Thermocouple Elements

SKU: BLCDN-8M12L-4AI-TC-4AI-TC

I/O Module, Compact station · Analog input, Temperature · M12

$1,408.50

List price. Volume pricing available.

Qty:

Authorized Dealer

Calibration Available

Nationwide Shipping

Expert Support

BL compact fieldbus station for DeviceNet — 8 Analog Inputs for Thermocouple Elements

On-machine Compact fieldbus I/O block
DeviceNet slave
125 / 250 / 500 kbps
Two 5-pole M12 connectors for fieldbus connection
2 rotary switches for node address
IP67, IP69K
M12 I/O connectors
LEDs indicating status and diagnostics
Electronics galvanically separated from the field level via optocouplers
8 analog inputs for Thermo Couples
Types B, C, E, G, J, K, N, R, S or T (selectable per channel)
Cold-junction compensation via a Pt1000 in special connector

Have questions about this product?

Our team can help with product selection, specs, pricing, and application support.

eCl@ss-Code (V5.1.4)	27250313 -/- Communication interface, passive
Customs tariff number	8536908530
Country of origin	DE
Weight	637.3 g
Fieldbus Protocol	DeviceNet
Signal type	Analog input, Temperature
Connection technology signal	M12
Device type	I/O Module, Compact station
Fieldbus transmission rate	125/250/500 kbps
Fieldbus connection technology	2 × M12
Ambient temperature	-40…+70 °C
Protection class	IP67/IP69K

eCl@ss-Code (V5.1.4)	27250313 -/- Communication interface, passive
Customs tariff number	8536908530
Country of origin	DE
Weight	637.3 g
Fieldbus Protocol	DeviceNet
Signal type	Analog input, Temperature
Connection technology signal	M12
Device type	I/O Module, Compact station
Fieldbus transmission rate	125/250/500 kbps
Fieldbus connection technology	2 × M12
Ambient temperature	-40…+70 °C
Protection class	IP67/IP69K
