BL compact fieldbus station for DeviceNet - 4 Analog Inputs for Current or Voltage and 4 Analog Outputs for Voltage

BL compact fieldbus station for DeviceNet — 4 Analog Inputs for Current or Voltage and 4 Analog Outputs for Voltage

• On-machine Compact fieldbus I/O block
• DeviceNet slave
• 125 / 250 / 500 kbps
• Two 5-pole M12 connectors for fieldbus connection
• 2 rotary switches for node address
• IP67, IP69K
• Reverse keyed M12 I/O connectors
• LEDs indicating status and diagnostics
• Electronics galvanically separated from the field level via optocouplers
• 4 analog inputs for current or voltage
• 0/4…20 mA or -10/0…+10 VDC (selectable per channel)
• 4 analog voltage outputs
• -10/0…+10 VDC
• CS30028: Scheduled and summarized diagnostics data disabled (I/O data size reduced)

The Turck BL compact fieldbus station for DeviceNet - 4 Analog Inputs for Current or Voltage and 4 Analog Outputs for Voltage # BLCDN-4M12WMT-4AI4AO-VI/CS30028 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
