SKU: PT1VR-1001-IOL-H1141
-14…0 psi · G 1/4” female thread (front sealing) · 2 × switching output · 18…33 VDC
List price. Volume pricing available.
Pressure Transmitter — With 2 Switching Outputs and IO-Link
The Turck Pressure Transmitter - With 2 Switching Outputs and IO-Link # PT1VR-1001-IOL-H1141 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101522556 |
| eCl@ss-Code (V5.1.4) | 27200614 -/- Piezoresistive sensor (absolute and relative pressure) |
| Customs tariff number | 9026204000 |
| Country of origin | CH |
| Weight | 103 g |
| Design | Without display |
| Process connection | G 1/4” female thread (front sealing) |
| Pressure type | Relative pressure |
| Pressure range bar | -1…0 bar |
| Pressure range psi | -14…0 psi |
| Operating voltage | 18…33 VDC |
| Electrical output | 2 × switching output |
| Communication protocol | IO-Link |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0 |
| Material pressure transducer | Ceramic Al₂O₃ |
| Medium temperature | -40…+125 °C |
| Ambient temperature | -30…+85 °C |
| Protection class | IP67 |
| Approvals | CE, Metrological certification (RUS), cULus |
This product is part of a family with 126 models. Select a model below to view details.
| Model | Price | |
|---|---|---|
PT1VR-1001-I2-H1143 | Request Quote | View Details → |
PT1VR-1001-U1-H1141 | Request Quote | View Details → |
PT1VR-1001-U1-H1143 | Request Quote | View Details → |
PT1VR-1121-U6-DT043P | Request Quote | View Details → |
PT1VR-1001-IOL-H1141Current | Request Quote | Viewing |
PT1VR-1013-IOL-H1141 | Request Quote | View Details → |
PT1VR-1003-IOL-H1141 | Request Quote | View Details → |
PT0.05V-1503-I2-H1143/D840 | Request Quote | View Details → |
PT0.2V-1003-I2-H1143 | Request Quote | View Details → |
PT0.2V-1004-I2-H1143 | Request Quote | View Details → |
