MPAC128-ATEX Hazardous-Area Acoustic Imaging Camera

Professional Acoustic Imaging Camera (II 3G Ex ic IIC T5 Gc explosion-proof)

The MPAC128-ATEX is designed for hazardous Zone 2 areas and provides ATEX-certified safety without compromising performance. Identifying gas, pressure, and vacuum leaks, as well as corona, arcing, and partial discharge faults up to 120 meters away, including challenging areas, this model ensures prompt action to restore safety and system integrity in finished products, process plants, and electrical installations. The MPAC 128-ATEX quipped with 128 sensors, this high-resolution acoustic imager

The MPAC128 series also packs impressive reliability with the units ingenious self-check function, meticulously verifying internal components’ integrity and guaranteeing flawless operation of the microphone array, providing unwavering performance day in, day out.

Megger Professional Acoustic Imaging Cameras Overview

Megger MPAC128 and MPAC128-ATEX are hand-held professional acoustic imagers that support both audible and ultrasonic frequencies. The MPAC128-ATEX features a II 3G Ex ic IIC T5 Gc explosion-proof rating.

Key Features

• Designed for hazardous Zone 2 areas, and provides ATEX-certified safety
• Detects multiple gas types, pressurized gas leaks, and partial discharge
• Phase Resolved Partial Discharge (PRPD) for discrimination between different types of partial discharge
• Analyze waveform, spectrum, spectrogram, leakage assessment, discharge type discrimination
• IP54 rating; Wide operating temperature range from -20 to 50 degrees Celsius
• 8MP optical camera resolution; 3.04mm fixed focal length; Sound/Camera FOV: Horiz. - 62°; Vert. - 48°
• Microphone array: 128 channels MEMS microphones; Detection range: 0.3 – 120 meters
• Frequency band: 2kHz to 48kHz; Dynamic range: 0.5 dB to 12 dB (user adjustable)
• Leak detection rate: 1m 7 bar 0.37ml/s; 10m 7 bar 0.7ml/s
• 7in touchscreen display (Grayscale, Ironbow, Rainbow); Resolution 1024 x 600

The Megger MPAC128-ATEX Hazardous-Area Acoustic Imaging Camera # 1015-885 is manufactured by Megger. Valley Instrument Service is an authorized Megger dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
