EVCC300 Electric Vehicle Charger Checker

Electric Vehicle Charger Checker

The new EVCC300 introduces a new and convenient way of checking Electric Vehicle charge points. A simple all in one concept provides an easy-to-use solution to check both the safety and operation of mode 2 and single phase mode 3 (level 1 and two phase level 2) EV chargers. The instrument is ideal for those wishing to perform a check on an EV charger following manufacture, installation or repair, or just part of a maintenance schedule / inspection.

1. PE touch pad to check ground connection and hazardous voltages.

2. PE resistance (RPE) test to check any exposed metal work is properly grounded / earthed.

3. Touch voltage test to ensure the charger ground / earth does not rise to a hazardous level when charger output is on.

Key Features

• Checks mode 2 and single phase mode 3 (level 1 and two phase level 2) chargers
• Checks chargers with SAE J1772 Type 1 and Type 2 connectors
• Performs four EV charger safety checks
• Performs four EV charger operation checks
• Checks to see if nuisance tripping or RCD/GFCI is likely to occur
• Reads control pilot state response from EV Charger to IEC61852-1

The Megger EVCC300 Electric Vehicle Charger Checker # 1013-576 is manufactured by Megger. Valley Instrument Service is an authorized Megger dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
