SKU: FLUKE-719PRO-30G
Fluke 719Pro Electric Pressure Calibrator includes a loop calibrator that sources, simulates & measures mA signals +. Eliminate over-pressurization. Get specs.
List price. Volume pricing available.
Fluke 719Pro Electric Pressure Calibrator includes a loop calibrator that sources, simulates & measures mA signals +. Eliminate over-pressurization. Get specs.
The Fluke 719PRO-30G Electric Pressure Calibrator, 30 PSIG # FLUKE-719PRO-30G is manufactured by Fluke. Valley Instrument Service is an authorized Fluke dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| General | Measurement |
| Range | -12 to 30 psi / -0.8 to 2 bar |
| Resolution | 0.001 psi / 0.0001 bar |
| Accuracy | ±0.025% of full scale, 6 months±0.035% of full scale, 1 year |
| Temperature effect (all ranges) | Add ±0.002% F.S./°C for temps outside of 15°C to 35°C |
| Fluke-719Pro-300G | Dry air and non-corrosive gas onlyNo effect on accuracy on all functions from 15°C to 35°C |
| Function | Range |
| 0-24 mA DC | 0.001 mA |
| mA DC (simulation and measurement) | 1000 ohm maximum load in mA source, 26 V DC maximum voltage in mA simulate |
| 30 V DC | 0.001 V |
| Volts DC (measurement only) | No AC voltage measurement, do not exceed 30 V DC |
| -50 to 150°C(-50°F to 302°F) | 0.01°C0.01°F |
| Temperature (measurement only, Pt100 RTD) | ±0.25°C (±0.45°F) combined uncertainty when using 720 RTD probe (optional accessory) |
| Loop power supply | 24 V DC |
| - | - |
| Temperature effect (all functions) | No effect on accuracy on all functions from 15°C to 35°C |
| Operating temperature | -10°C to +50°C |
| Storage temperature (with batteries) | Per battery manufacturer's specification within storage specification below |
| Storage temperature (without batteries) | -20°C to +60°C |
| Battery | Eight (8) standard Alkaline AA batteries |
| Battery life | 300 pump cycles to 150 psi minimum; 1000 pump cycles to 30 psi; 100 pump cycles to 300 psi minimum |
| Dimensions (H x W x D) | 24.13 x 11.18 x 7 cm (9.5 x 4.4 x 2.8 in) |
| Weight | With holster 1.2 kg (2.5 lb) |
| Pressure | 1/8 inch female NPT |
| Electrical | Standard banana jacks |
| RTD | 4 pin miniature circular |
| External module | 6 pin miniature circular |
This product is part of a family with 3 models. Select a model below to view details.
| Model | Price | |
|---|---|---|
FLUKE-719PRO-30GCurrent | Request Quote | Viewing |
FLUKE-719PRO-150G | Request Quote | View Details → |
FLUKE-719PRO-300G | Request Quote | View Details → |
